Package architecture and function reference

Pablo Fuenzalida

2026-05-26

Source: vignettes/architecture-and-functions.Rmd
architecture-and-functions.Rmd
library(sharkipediaR)
library(dplyr)
#>
#> Attaching package: 'dplyr'
#> The following objects are masked from 'package:stats':
#>
#>     filter, lag
#> The following objects are masked from 'package:base':
#>
#>     intersect, setdiff, setequal, union

vignette_fixture <- function(name) {
  path <- system.file("fixtures", name, package = "sharkipediaR")
  if (!nzchar(path)) {
    cli::cli_abort("Fixture not found: {name}")
  }
  path
}

doc <- xml2::read_html(vignette_fixture("carcharhinus_acronotus.html"))
index_doc <- xml2::read_html(vignette_fixture("species_index_page1.html"))
source_url <- "https://www.sharkipedia.org/species/carcharhinus-acronotus"
retrieved_at <- as.POSIXct("2026-05-25 12:00:00", tz = "UTC")

Design philosophy

sharkipediaR follows a strict pipeline:

HTTP retrieval  →  HTML parsing  →  cleaning  →  validation  →  user-facing tibble
(fetch.R)         (parse.R)        (clean.R)     (validate.R)   (sp_*.R)

No step is allowed to “do everything.” That separation keeps the package maintainable when Sharkipedia’s HTML evolves.

Data flow for sp_traits()

Data flow for sp_traits()

R/constants.R

Object / function Role
.sharkipedia_env Package-private environment storing last request time for rate limiting
sharkipedia_base_url() Returns https://www.sharkipedia.org
sharkipedia_user_agent() Identifies the client in HTTP headers (version + project URL)

These are internal but underpin polite scraping.

R/utils.R

rate_limit_pause(min_gap = 0.5)

Waits until at least min_gap seconds have elapsed since the last request, plus a small random jitter (runif(0, 0.3)). Called automatically by fetch_page().

species_name_to_slug(name)

Converts "Carcharhinus acronotus" → "carcharhinus-acronotus" (lowercase, spaces to hyphens).

species_name_to_url(name)

Builds the full species page URL from a scientific name.

sharkipediaR:::species_name_to_url("Carcharhinus acronotus")
#> [1] "https://www.sharkipedia.org/species/carcharhinus-acronotus"

normalize_sharkipedia_url(url)

Accepts:

  • full URLs,
  • relative paths (/species/...),
  • bare scientific names.

resolve_species_url(x)

Length-1 resolver used by all sp_*() functions. Errors if length(x) != 1.

ensure_species_vector(x)

Trims, de-duplicates, and validates a character vector for batch functions.

read_html_fixture(path)

Reads local HTML for tests (internal).

get_fetch_page(cache = TRUE)

Returns either fetch_page or memoised fetch_page_memoised depending on the cache argument passed to user functions.

R/fetch.R

fetch_page(url, quiet = TRUE) — exported

Responsibilities only: HTTP, rate limit, retries, return xml_document.

Step Implementation
URL normalisation normalize_sharkipedia_url()
Politeness rate_limit_pause()
Request httr2::request() + user agent + req_retry(max_tries = 3)
Error handling Abort on status ≥ 400 with cli message
Body httr2::resp_body_html() → xml2 document
doc_live <- fetch_page("Carcharhinus acronotus", quiet = FALSE)
class(doc_live)

fetch_page_memoised

memoise::memoise(fetch_page) — identical URLs in one R session return the cached document without a new HTTP call.

R/parse.R

Parsing functions never perform HTTP. They only read xml_document objects.

parse_species_index(doc)

Used by: sp_species_urls()

  • Selector: a[href^='/species/']
  • Excludes CSV export links (*.csv slugs)
  • Returns species, slug, url
idx <- sharkipediaR:::parse_species_index(index_doc)
head(idx, 4)
#> # A tibble: 4 × 3
#>   species             slug                              url
#>   <chr>               <chr>                             <chr>
#> 1 Rajella leopardus   rajella-leopardus                 https://www.sharkipedia…
#> 2 Gymnura lessae      gymnura-lessae                    https://www.sharkipedia…
#> 3 Styracura schmardae html-i-styracura-schmardae-i-html https://www.sharkipedia…
#> 4 Dipturus lamillai   dipturus-lamillai                 https://www.sharkipedia…

parse_index_last_page(doc)

Reads Bulma pagination links (.pagination-link) and returns the maximum page number — used when sp_species_urls(all_pages = TRUE).

parse_taxonomy(doc)

Used by: sp_species()

  • Species name: h1.title
  • Ranks: div.columns > div.column:first-child > p with labels Superorder:, Subclass:, Order:, Family:
sharkipediaR:::parse_taxonomy(doc)
#> # A tibble: 1 × 5
#>   species                superorder   subclass       order             family
#>   <chr>                  <chr>        <chr>          <chr>             <chr>
#> 1 Carcharhinus acronotus Galeomorphii Elasmobranchii Carcharhiniformes Carcharh…

Trait table helpers

Function Role
trait_table_headers() Reads <thead><th> text
is_trait_table() TRUE if headers include "Name"
preceding_trait_group() XPath preceding::h4[contains(@class,'subtitle')][1] for trait class

parse_traits_tables(doc)

Used by: sp_traits() via fetch_species_traits()

  1. Find all table.table elements.
  2. Keep tables whose headers match Sharkipedia’s trait schema.
  3. rvest::html_table() for body rows.
  4. Attach trait_group from the nearest preceding h4.
raw_traits <- sharkipediaR:::parse_traits_tables(doc)
names(raw_traits)
#> [1] "Name"        "Value"       "Standard"    "ValueType"   "Sex"
#> [6] "Location"    "Reference"   "trait_group"
head(raw_traits, 3)
#> # A tibble: 3 × 8
#>   Name             Value Standard ValueType Sex   Location Reference trait_group
#>   <chr>            <chr> <chr>    <chr>     <chr> <chr>    <chr>     <chr>
#> 1 Direct Predation Medi… Effect … mean      Pool… Caribbe… clementi… Ecological…
#> 2 Direct Predation Medi… Strengt… mean      Pool… Caribbe… clementi… Ecological…
#> 3 Amat50           4.3   Year     mean      Male  South C… driggers… Age

Note: column names are still PascalCase (Name, Value, …) at this stage.

decode_react_props(props)

Decodes HTML entities in data-react-props JSON and parses with jsonlite. Internal helper for trends.

Used by: sp_trends()

  1. Locate the first table after the h3 heading containing "Trends".
  2. For each <tr>:
    • location, unit, reference from table cells
    • trend_id / trend_url from the “Details” link
    • observations matrix from div[data-react-props]
  3. Expand to one row per year × value.
raw_trends <- sharkipediaR:::parse_trends_tables(doc)
raw_trends %>%
  count(location, trend_id) %>%
  head(5)
#> # A tibble: 5 × 3
#>   location                                      trend_id     n
#>   <chr>                                         <chr>    <int>
#> 1 Brownsville, TX to the Florida Keys, FL (USA) 3540        23
#> 2 North Carolina to Brownsville (USA)           3537        26
#> 3 North Gulf of Mexico                          3543        60
#> 4 North Gulf of Mexico                          3544        60
#> 5 North Gulf of Mexico (USA)                    3538        22

parse_references(doc)

Collects unique a[href^='/references/'] from trait and trend tables.

sharkipediaR:::parse_references(doc) %>% head(5)
#> # A tibble: 5 × 2
#>   reference_id      reference_url
#>   <chr>             <chr>
#> 1 clementi2021      https://www.sharkipedia.org/references/clementi2021
#> 2 driggers2004a     https://www.sharkipedia.org/references/driggers2004a
#> 3 trinidadcruz1997  https://www.sharkipedia.org/references/trinidadcruz1997
#> 4 uribemartinez1993 https://www.sharkipedia.org/references/uribemartinez1993
#> 5 peterson2017      https://www.sharkipedia.org/references/peterson2017

link_text_or_href(node)

Utility for anchor text vs. href basename (internal).

R/clean.R

Cleaning standardises names, types, and provenance.

standardize_trait_columns(df)

Maps Sharkipedia headers to snake_case:

HTML R column
Name trait_name
Value value
Standard standard
ValueType value_type
Sex sex
Location location
Reference reference

clean_traits(df, species, source_url, retrieved_at)

  • Renames columns via standardize_trait_columns()
  • Adds species, source_url, retrieved_at (UTC POSIXct)
  • str_squish() + na_if("", .) on character fields
  • Strips /references/ prefixes from reference
traits_clean <- sharkipediaR:::clean_traits(
  raw_traits,
  species = "Carcharhinus acronotus",
  source_url = source_url,
  retrieved_at = retrieved_at
)
names(traits_clean)
#>  [1] "trait_name"   "value"        "standard"     "value_type"   "sex"
#>  [6] "location"     "reference"    "trait_group"  "species"      "source_url"
#> [11] "retrieved_at"

clean_trends(df, species, source_url, retrieved_at)

  • Coerces year to integer, keeps value as double
  • Adds species and provenance columns
  • Squashes whitespace on metadata fields
trends_clean <- sharkipediaR:::clean_trends(
  raw_trends,
  species = "Carcharhinus acronotus",
  source_url = source_url,
  retrieved_at = retrieved_at
)
summary(trends_clean$year)
#>    Min. 1st Qu.  Median    Mean 3rd Qu.    Max.
#>    1950    1970    1989    1986    2001    2018

R/validate.R

Validation is the last gate before data reach the user.

validate_traits(df)

  • Required columns: species, trait_name, value, source_url, retrieved_at
  • Warns (does not error) on zero rows — page structure may have changed

validate_trends(df)

  • Required columns: species, year, value, source_url, retrieved_at
  • Same empty-data warning pattern
sharkipediaR:::validate_traits(traits_clean) %>% nrow()
#> [1] 39
sharkipediaR:::validate_trends(trends_clean) %>% nrow()
#> [1] 321

R/sp_species_urls.R

sp_species_urls(all_pages = FALSE, max_pages = NULL, cache = TRUE)

Argument Behaviour
all_pages = FALSE Only page 1 of ?all=true index (~20 species)
all_pages = TRUE Reads pagination from page 1, loops all pages
max_pages Caps pagination when exploring
cache Uses memoised fetch_page

Returns deduplicated tibble: species, slug, url.

sp_species_urls()
sp_species_urls(all_pages = TRUE, max_pages = 3)

R/sp_search.R

sp_search(query, index = NULL, all_pages = FALSE, cache = TRUE)

  1. Normalises query via ensure_species_vector().
  2. Builds or accepts index tibble.
  3. grepl(..., fixed = TRUE) on lowercased species and slug.
  4. distinct(url).

Best practice: idx <- sp_species_urls(all_pages = TRUE) once, then sp_search("rhincodon", index = idx).

R/sp_species.R

sp_species(species, cache = TRUE)

End-user taxonomy extractor. Returns one row:

species, superorder, subclass, order, family, source_url, retrieved_at

ex <- example_carcharhinus()
ex$species_meta
#> # A tibble: 1 × 7
#>   species        superorder subclass order family source_url retrieved_at
#>   <chr>          <chr>      <chr>    <chr> <chr>  <chr>      <dttm>
#> 1 Carcharhinus … Galeomorp… Elasmob… Carc… Carch… https://w… 2026-05-25 12:00:00

R/sp_traits.R

sp_traits(species, cache = TRUE)

Public API for traits.

  • One species: calls fetch_species_traits().
  • Many species: purrr::map_dfr() with column species_input.

fetch_species_traits(species, cache = TRUE) — internal

Orchestrates the full trait pipeline documented above.

# Equivalent to fetch_species_traits() without HTTP:
traits_clean <- sharkipediaR:::validate_traits(traits_clean)
nrow(traits_clean)
#> [1] 39

sp_trends(species, cache = TRUE)

Public API for population trends (long format).

fetch_species_trends(species, cache = TRUE) — internal

Same pattern as traits: fetch → parse → clean → validate.

nrow(trends_clean)
#> [1] 321

R/sp_references.R

sp_references(species, cache = TRUE)

Fetches species page, runs parse_references(), adds species, source_url, retrieved_at.

Use to build a reference lookup table before joining to traits/trends.

R/example_data.R

example_carcharhinus() — exported

Loads inst/extdata/carcharhinus_acronotus.rds — a list with pre-parsed components used in all vignettes.

Rebuild after fixture updates:

source("data-raw/build-vignette-data.R")

End-to-end manual pipeline (advanced users)

Reproduce sp_traits() without calling it:

url <- sharkipediaR:::species_name_to_url("Carcharhinus acronotus")
# doc <- fetch_page(url)   # live
# raw <- parse_traits_tables(doc)
# out <- validate_traits(clean_traits(raw, "Carcharhinus acronotus", url))
# Identical structure to example_carcharhinus()$traits

This is the extension point if Sharkipedia adds a JSON API later: swap fetch_page() + parse_*() implementations while keeping sp_traits() stable.

Testing and pkgdown

See Getting started and Ecological workflows for ggplot demonstrations and scientific motivation.
